- Motor shaft manufactured in stainless steel AISI 316L.
- Pre-filter basket in stainless steel, too.
- Motors with IP-55 protection, at 3,000 rpm, 230/400V-50Hz or 400/690V-50Hz (7.5, 10, and 12.5 HP) three-phase.
- Versions from 4HP to 12.5HP.
- Possibility of AISI 316L stainless steel impellers upon request.
Technical Datasheet
| Model | Power | Manometric Height w.c.m. | Connection Size | Strainer Volume | Noise | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| HP | kW | RPM | 6 | 8 | 10 | 12 | 14 | 16 | ||||
| Flow m³/h | ANSI / DIN | L | dB | |||||||||
| AMX55 | 5.5 | 4 | 2850 | 95 | 90 | 82 | 75 | 65 | 50 | 4" / DN100 | 13 | 72 |
| AMX75 | 7.5 | 5.5 | 2850 | 130 | 120 | 110 | 105 | 90 | 80 | 4" / DN100 | 13 | 72 |
| AMX100 | 10 | 7.5 | 1450 | – | 210 | 185 | 180 | 160 | 135 | 6" / DN150 | 30 | 68 |
| AMX150 | 15 | 11 | 1450 | – | 270 | 260 | 250 | 240 | 210 | 6" / DN150 | 30 | 68 |
