Atecpool Bobinados Commercial Filters

Filters supplied with flange connection from 3” to 8” for connection to a battery of 4/5 butterfly valves
For ozone applications, filters can be lined with vinyl-ester on demand
Standard internal distribution system: collector arms
The distance between the upper part of the sand layer and the diffuser head is increased to ensure greater distribution of water in the filtration phase and to avoid sand spill into the laterals during backwashing
Valve manifold frontal piping or Butterfly valve assembly to be ordered separately

Code	Diameter Ø (mm)	Filtration Velocity (m³/h/m²)	Flow Rate (m³/h)	Valve Connection	Filtration Area (m²)	Sand (kg)	Gravel (kg)
06831200	1200	30	33	3″	1.13	700	400
06831200	1200	40	45	3″	1.13	700	400
06831400	1400	30	46	4″	1.54	1000	500
06831400	1400	40	61	4″	1.54	1000	500
06831600	1600	30	60	4″	2.01	1450	800
06831600	1600	40	80	4″	2.01	1450	800
06831800	1800	30	76	6″	2.54	2400	1350
06831800	1800	40	101	6″	2.54	2400	1350
06832000	2000	30	94	6″	3.14	2800	1400
06832000	2000	40	125	6″	3.14	2800	1400
06832350	2350	30	130	8″	4.34	5600	1700
06832350	2350	40	173	8″	4.34	5600	1700
06832500	2500	30	147	8″	4.90	6400	2000
06832500	2500	40	196	8″	4.90	6400	2000

Product Dimensions

Model	Diameter Ø (mm)	A (mm)	B (mm)	C (mm)	D (mm)	E (mm)	F (mm)	G (mm)	H (mm)
06831200	1200	170	565	350	915	1410	1200	1000	720
06831400	1400	190	565	350	915	1570	1400	1220	760
06831600	1600	200	650	350	1000	1740	1620	1365	820
06831800	1800	220	690	415	1105	2040	1790	1630	950
06832000	2000	220	770	415	1185	2210	1945	1630	1020
06832350	2350	230	950	550	1500	2510	2375	1800	1200
06832500	2500	230	1050	550	1600	2670	2495	1800	1290

Included and Optional Equipment

Included
Air purge connection: 20 mm.

Optional
Side manhole Ø400 mm, sight glass 114 mm, nozzle plate distributor and 4 kg/cm² working-pressure construction.

Automatic Air Release
Automatic air release valve is available upon request.

Valve Manifold

Frontal piping or butterfly-valve assembly must be ordered separately.
Filters with special heights can be produced upon request.
Filters with a diameter of 2350 mm and above may require special transportation.
