| Description | 10 g/h | 16 g/h | 22 g/h | 28 g/h |
|---|---|---|---|---|
| Model – Invertek Premium | IKS10 | IKS16 | IKS22 | IKS28 |
| Model – Invertek Standard | IKM10 | IKM16 | IKM22 | IKM28 |
| Production (g/h, 3000 PPM) | 10.0 | 16.0 | 22.0 | 28.0 |
| Advised Pool Volume* (m³) | 15–45 | 25–65 | 35–75 | 45–100 |
| Power Consumption (W) | 60 | 85 | 110 | 130 |
| Technical Specification | Details |
|---|---|
| Advised Water Flow | 5–18 m³/h |
| Power Supply | 100–240 V, 50/60 Hz |
| Operating Temperature | -5 to 42°C |
| Operating Salt Level | As low as 3 g/L |
| Salinity Test | Salt Level Detection (accuracy ±500 PPM) |
| Self-cleaning | Default 4 h, 3 options in total (2 / 4 / 6 h) |
| pH Dosing Pump | Integrated |
| Communications | MODBUS RS485 / Wi-Fi / Dry Contact |
| Control Unit Dimension (L×W×H) | 270 × 205 × 75 mm |
| Water Connection | 63 mm |
| Electrodes | Titanium plates |
| Water Temperature | 10–40°C |
| Maximum Pressure | 3.0 bar for Probe Cell; 4.5 bar for Electrolysis Cell |
| Cell Life | 10,000 hours |
