Atecpool Taurus Dosing Pumps

Motor Driven Dosing Pumps
ELECTROMECHANICAL DOSING PUMPS

Mechanical diaphragm metering pumps featuring a spring return mechanism and an aluminium housing.
Each pump is equipped with manual flow adjustment and can be equipped with an electric actuator that accepts a 4-20 mA signal or an inverter.

Model	Diaphragm Ø	Stroke Length	Strokes/Min.	Flow Rate	Pressure	Connection	Weight
TM02094A	94 mm	2 mm	58	20 L/h	10 bar	3/8″	8.4 kg
TM2094B	94 mm	2 mm	78	26 L/h	10 bar	3/8″	8.4 kg
TM02094C	94 mm	2 mm	116	40 L/h	10 bar	3/8″	8.4 kg
TM04108A	108 mm	4 mm	58	60 L/h	10 bar	3/8″	10.1 kg
TM04108B	108 mm	4 mm	78	80 L/h	10 bar	3/8″	10.1 kg
TM04108C	108 mm	4 mm	116	120 L/h	10 bar	3/8″	10.1 kg
TM06138A	138 mm	6 mm	58	155 L/h	7 bar	3/4″	12.3 kg
TM06138B	138 mm	6 mm	78	220 L/h	7 bar	3/4″	12.3 kg
TM06138C	138 mm	6 mm	116	310 L/h	7 bar	1″	12.3 kg
TM06165A	165 mm	6 mm	58	230 L/h	5 bar	1″	13.2 kg
TM06165B	165 mm	6 mm	78	330 L/h	5 bar	1″	13.2 kg
TM06165C	165 mm	6 mm	116	500 L/h	3 bar	1″	13.2 kg
