Benefits of Ozone Generation
- Ozone is many times more effective than chemical water treatment.
- Ozone prevents the formation of chloramines.
- Ozone breaks down chloramines.
- Ozone is effective against chlorine-resistant organisms, algae, bacteria and viruses.
- Ozone makes your water crystal clear, odorless and healthy again.
Pzone Components
- Air dryer / Oxygen concentrator
- Ozone generation
- Auxiliary pump
- Injector
- Reaction / Degassing tank
- Degassing valve
- Ozone destroyer in degassing tank
Ozone Efficiency
- Disinfectant
- Decolourisation
- Removal of contaminants
- Deodorisation
| Specification | Details |
|---|---|
| Technology | Ozone Water Treatment |
| Ozone Production | 2–12.5 gO₃/h |
| Application | Public / Private Pools |
| Pool Volume | 200–1,200 m³ |
| Ozone Generation | Air Dryer / Oxygen Concentrator |
| Power Control | 10–100% |
| Installation | Plug and Play |
| Connection System | In By-pass |
| Model | Ozone Generation | Ozone Production | Private Pool | Public Pool | Input Power | Dimensions | Weight |
|---|---|---|---|---|---|---|---|
| Exclusive 2,EP | Air Dryer | 2.0 gO₃/h | Up to 200 m³ | Up to 100 m³ | 1.0 kW | 550 × 450 × 1,100 mm | 55 kg |
| Exclusive 4,EP | Air Dryer | 4.0 gO₃/h | Up to 400 m³ | Up to 200 m³ | 1.1 kW | 550 × 450 × 1,100 mm | 57 kg |
| Exclusive 12,EP | Oxygen Concentrator | 12.5 gO₃/h | Up to 1,200 m³ | Up to 600 m³ | 1.6 kW | 1,100 × 500 × 1,200 mm | 121 kg |
