PTH 40 -300 kW

These plate heat Exchanger have been made to heat bathing water with warm water. They are calculated at a temperature of 70/60/50/40°C and have an operating range from 15 to 300 kW. Take advantage of the bolted plate heat Exchanger, which feature high energy efficiency at low pressure loss, and are available in stainless steel AISI 316 or titanium.

Calculation information for the capacity on the secondary side

The plate heat Exchanger are calculated based on a pool water temperature (secondary) of 20°C. If you desire a pool water temperature of, e.g., 30°C, you should pick the row with 10°C less in the primary circuit to accurately capture the real performance of the plate exchanger.
