| Specification | Wave Linear LED Neon Strip | Wave Linear RGB LED Multicolor Strip |
|---|---|---|
| Code | ATL07 | ATL07 RGB |
| Type of Light | SMD3528 | SMD5050 Tri-chip |
| Colour Temperature / Selection | 6500K / 5000K / 3000K / 2700K | RGB – Blue / Red / Green |
| Material Used | ECO PVC | ECO PVC |
| Operating Voltage | 24V DC | 24V DC |
| Power Consumption | 10W/m | 12W/m |
| Lumen | 400 lm | 220 lm |
| LED Quantity / mtr | 144 pcs | 60 pcs |
| Min. Cutting Length | 3.28″ / 8.33 cm | 3.94″ / 10 cm |
| Max. Length | 20 mtr | 10 mtr |
| Protection Rating | IP68 | IP68 |
| Maximum Bending | Diameter 12 cm | Diameter 12 cm |
| Bending Direction | Vertically | Vertically |
| Ambient Temperature | -30°C to +45°C | -30°C to +45°C |
| Controller | 24V DC Power Supply | PWM Controller |
Mounting Channels
ATLA014: Aluminium mounting channel 1m
Dimensions: 20.4~16.2×19.6 mm (WxH)
ATLA014-SS : Stainless steel 304 mounting channel 1m
Dimensions: 18~15.91×21.8 mm (WxH)
